CF-E355AC - Dual band Wifi AP (1200 MBPS)

Art. nr: 107803
Logg inn for å handle

CF-E355AC - Dual band Wifi AP (1200 MBPS)

Data:

Hardware specifications

ATHEROS AR9341 400MHZ RF 64MB DDR 16M Flash (The New Chip)
Frequency Range & Channels:    2.4~2.4835GHz;20MHz,40MHz
RF Power Output:     24dBm
Modulation Mode:    DBPSK,DQPSK,CCK,OFDM,16-QAM,64-QAM

Data and operational parameters

Auto transmission rate selection:    802.11n: 6.5-300Mbps
802.11g: 6/9/12/18/24/36/48/54/108Mbps
802.11b: 1/2/5.5/11Mbps
Support WLAN Standards:    IEEE 802.11b/g/n, IEEE 802.3u, IEEE 802.3af
Support Protocols:    CSMA/CA, TCP/IP, IPX/SPX, NetBEUI, DHCP, NDIS3/4/5

Using Environment & Physically Properties

Using Environment    Physically Properties
Working Temperature:    -30°C~65°C      Product Weight:    0.855KG(Net) / 1.24KG(Gross)
Storage Temperature:    -50°C~80°C    Product Size:    205x205x38.5(mm)
Humidity(Non Condensing):      ≤95%    Package Size:    350x250x90(mm)

Management

Based on WEB Management:    Support
SNMP MIB:    Support
Telnet:     Support
Security
MAC Address Control:    Support
Encryption:    Support 64/128 bits WEP, WPA, WPA2, 802.1X
Antenna
Frequency Range:    2.4~2.4835GHz
Polarization Mode:    Vertical, Horizontal
Antenna Gain:    5dBi

CF-E355AC - Dual band Wifi AP (1200 MBPS)

Data:

Hardware specifications

ATHEROS AR9341 400MHZ RF 64MB DDR 16M Flash (The New Chip)
Frequency Range & Channels:    2.4~2.4835GHz;20MHz,40MHz
RF Power Output:     24dBm
Modulation Mode:    DBPSK,DQPSK,CCK,OFDM,16-QAM,64-QAM

Data and operational parameters

Auto transmission rate selection:    802.11n: 6.5-300Mbps
802.11g: 6/9/12/18/24/36/48/54/108Mbps
802.11b: 1/2/5.5/11Mbps
Support WLAN Standards:    IEEE 802.11b/g/n, IEEE 802.3u, IEEE 802.3af
Support Protocols:    CSMA/CA, TCP/IP, IPX/SPX, NetBEUI, DHCP, NDIS3/4/5

Using Environment & Physically Properties

Using Environment    Physically Properties
Working Temperature:    -30°C~65°C      Product Weight:    0.855KG(Net) / 1.24KG(Gross)
Storage Temperature:    -50°C~80°C    Product Size:    205x205x38.5(mm)
Humidity(Non Condensing):      ≤95%    Package Size:    350x250x90(mm)

Management

Based on WEB Management:    Support
SNMP MIB:    Support
Telnet:     Support
Security
MAC Address Control:    Support
Encryption:    Support 64/128 bits WEP, WPA, WPA2, 802.1X
Antenna
Frequency Range:    2.4~2.4835GHz
Polarization Mode:    Vertical, Horizontal
Antenna Gain:    5dBi
